500-443 Advanced Administration and Reporting of Contact Center Enterprise Question and Answers

The role of CVP in UCCE/PCCE is queuing and self-service IVR, as it provides voice response applications that can interact with callers, collect information, and queue calls for treatment byagents or other destinations. References = [Cisco Unified Contact Center Enterprise Solution Reference Network Design (SRND), Release 12.5(1)], page 9

According to the Cisco Packaged Contact Center Enterprise Features Guide, Release 12.0 (1), a Post Call Survey is triggered by the hang-up event from the last agent1. When the agent hangs up, the call routing script launches a survey script. The value of the expanded call variable user.microapp.isPostCallSurvey controls whether the call is transferred to the Post Call Survey number. If user.microapp.isPostCallSurvey is set to y (the implied default), the call is transferred to the mapped post call survey number. If user.microapp.isPostCallSurvey is set to n, the call ends1. Therefore, to invoke the Post Call Survey successfully, the routing script logic should direct the call to the Post Call Survey dialed number after the agent disconnects from the caller. The other options are not correct, because they either do not involve an agent interaction or do not set the user.microapp.isPostCallSurvey variable correctly.

C CCE Managed Transfer is supported in PCCE Deployments, as it allows the agent to transfer a call to another agent or skill group within the same PCCE system using the Finesse desktop. E SIP Refer is supported in PCCE Deployments, as it allows the agent to transfer a call to an external destination using the SIP Refer method. References = [Cisco Unified Contact Center Enterprise Features Guide, Release 12.5(1)], page 43; [Cisco Unified Contact Center Enterprise Solution Reference Network Design (SRND), Release 12.5(1)], page 101

JNDI is designed to be independent of any specific directory service implementation so a variety of directories can be accessed, such as LDAP, NDS, or DNS. E JNDI is an API that provides naming and directory functionality to applications, such as looking up objects by name, binding objects tonames, and creating and destroying naming contexts. References = [Java Naming and Directory Interface (JNDI) Overview]

B The required number of conference bridge resources for Mobile Agent agent greetings with an Average greeting time of 10 secs and a Mobile Agent call rate of 8 secs is 18. This can be calculated by dividing the average greeting time by the call rate and multiplying by two (for duplexed PGs). For example: (10 / 8) x 2 = 2.5 x 2 = 5 conference bridge resources per PG pair. Since there are four PG pairs in a PCCE deployment, the total number of conference bridge resources is 5 x 4 = 20. References = [Cisco Unified Contact Center Enterprise Solution Reference Network Design (SRND), Release 12.5(1)], page 97

A switch leg on CVP refers to an ingress SIP call leg from Ingress gateway to CVP, as this is where CVP receives and controls incoming calls from PSTN or other networks. References = [Cisco Unified Contact Center Enterprise Solution Reference Network Design (SRND), Release 12.5(1)], page 11

A One of the conditions in which PCS legs get invoked is if Router Re-query is misconfigured and the Ring-No-Answer timeout expires, the caller is still transferred to the Post Call Survey DN. This can occur if a Queue node is used and Enable target re-query is checked, as this causes CVP to send a new routing request to CCE when no agent answers the call. B Another condition in which PCS legs get invoked is if The Post Call Survey DN is called if the Unified CVP has received at least one CONNECT message from CCE (either from the VRU leg or the Agent’s leg). Use the END node in the CCE routing script if the Post Call Survey is not required for the calls disconnected from the IVR, as this prevents CVP from transferring the call to the Post Call Survey DN when the call is terminated by the caller or the IVR. References = [Cisco Unified Contact Center Enterprise Features Guide, Release 12.5(1)], page 25

A Account Type is one of the usages for Call Studio Database lookup, as it allows the application to retrieve information about the caller’s account from a database and provide different treatments based on the account type. D Claim Number is another usage for Call Studio Database lookup, as it allows the application to validate the claim number entered by the caller against a database and provide confirmation or error messages accordingly. References = [Cisco Unified Call Studio User Guide Release 12.5(1)], page 47

B One of the destination patterns in the ingress gateway pointing to the number a customer dials considering the SIP comprehensive call flow is pointing to CVP IP address, as this allows CVP to receive and process incoming calls from the ingress gateway. C Another destination pattern in the ingress gateway pointing to the number a customer dials considering the SIP comprehensive call flow is pointing to IOS q/ws loopback address, as this allows CVP to send calls back to the ingress gateway for queuing and self-service. References = [Cisco Unified Contact Center Enterprise Solution Reference Network Design (SRND), Release 12.5(1)], page 11

The protocol used by UCCE/PCCE to communicate with CUCM is JTAPI, which stands for Java Telephony Application Programming Interface. JTAPI allows UCCE/PCCE to monitor and control agent phones and CTI ports on CUCM. References = [Cisco Unified Contact Center Enterprise Solution Reference Network Design (SRND), Release 12.5(1)], page 10

B One of the mandatory configurations for Mobile Agent to function is that LCP DN as a Route pattern should be created with the destination as CUCM in PCCE SPOG, as this allows CUCM to route calls from CVP to LCP DN. E Another mandatory configuration for Mobile Agent to function is that both LCP and RCP ports need to be associated with JTAPI, as this allows CCE to monitor and control the mobile agent ports on CUCM. References = [Cisco Unified Contact Center Enterprise Features Guide, Release 12.5(1)], page 27; [Cisco Unified Contact Center Enterprise Solution Reference Network Design (SRND), Release 12.5(1)], page 95

B One of the descriptions for the CUIC database is that the CUIC runs its own MySQL database storing users, roles, permissions, and report templates, as it provides a repository for CUIC configuration and customization data. C Another description for the CUIC database is that database purge schedule can be controlled or changed through the command-line interface, as it allows the administrator to set the frequency and duration of data purging for historical and real-time tables. References = [Cisco Unified Intelligence Center Installation and Upgrade Guide Release 12.5(1)], page 11; [Cisco Unified Intelligence Center User Guide Release 12.5(1)], page 10

• A. VXML Server and Virtual Voice Browser execute the VXML application to provide service to the caller. This is the core function of how Call Studio applications work. VXML (VoiceXML) defines the interaction, and the VXML Server, along with the Virtual Voice Browser, executes that code to interact with the caller.
• D. The project is built using Call Studio. Call Studio is the development environment specifically designed to create and manage these VXML applications
