2V0-41.23 - VMware NSX 4.x Professional

The answer is C. Group all by means of tags membership.

Tags are metadata that can be applied to physical servers, virtual machines, logical ports, and logical segments in NSX. Tags can be used for dynamic security group membership, which allows for granular and flexible enforcement of security policies based on various criteria1

In the scenario, the company is deploying NSX micro-segmentation to secure a simple application composed of web, app, and database tiers. The naming convention will be:

• WKS-WEB-SRV-XXX
• WKY-APP-SRR-XXX
• WKI-DB-SRR-XXX

The optimal way to group them to enforce security policies from NSX is to use tags membership. For example, the company can create three tags: Web, App, and DB, and assign them to the corresponding VMs based on their names. Then, the company can create three security groups: Web-SG, App-SG, and DB-SG, and use the tags as the membership criteria. Finally, the company can create and apply security policies to the security groups based on the desired rules and actions2

Using tags membership has several advantages over the other options:

• It is more scalable and dynamic than using Edge as a firewall between tiers. Edge firewall is a centralized solution that can create bottlenecks and performance issues when handling large amounts of traffic3
• It is more simple and efficient than doing a service insertion to accomplish the task. Service insertion is a feature that allows for integrating third-party services with NSX, such as antivirus or intrusion prevention systems. Service insertion is not necessary for basic micro-segmentation and can introduce additional complexity and overhead.
• It is more flexible and granular than creating an Ethernet based security policy. Ethernet based security policy is a type of policy that uses MAC addresses as the source or destination criteria. Ethernet based security policy is limited by the scope of layer 2 domains and does not support logical constructs such as segments or groups.

To learn more about tags membership and how to use it for micro-segmentation in NSX, you can refer to the following resources:

• VMware NSX Documentation: Security Tag 1
• VMware NSX Micro-segmentation Day 1: Chapter 4 - Security Policy Design 2
• VMware NSX 4.x Professional: Security Groups
• VMware NSX 4.x Professional: Security Policies

According to the web search results, error code 1001 is related to a time synchronization issue between the ESXi host and the NSX Manager. This can cause problems when configuring a time-based firewall rule, which requires the ESXi host and the NSX Manager to have the same time zone and NTP server settings . To resolve this error, you need to restart the NTP service on the ESXi host to synchronize the time with the NSX Manager. You can use the following command to restart the NTP service on the ESXi host:

/etc/init.d/ntpd restart

The other options are not valid solutions for this error. Reinstalling the NSX VIBs on the ESXi host will not fix the time synchronization issue. Changing the time zone on the ESXi host may cause more discrepancies with the NSX Manager. Reconfiguring the ESXi host with a local NTP server may not be compatible with the NSX Manager’s NTP server.

The four types of role-based access control (RBAC) permissions are Read, None, Full access, and Execute1. Read permission allows the user to view the configuration and status of the system. None permission denies any access to the system. Full access permission grants all permissions including Create, Read, Update, and Delete (CRUD). Execute permission includes Read and Update permissions1. Auditor, Enterprise Admin, and Network Admin are not types of permissions, but types of roles that have different sets of permissions. References: NSX Features

There are four types of permissions. Included in the list are the abbreviations for the permissions that are used in the Roles and Permissions and Roles and Permissions for Manager Mode tables.

• Full access (FA) - All permissions including Create, Read, Update, and Delete
• Execute (E) - Includes Read and Update
• Read (R)
• None

NSX-T Data Center has the following built-in roles. Role names in the UI can be different in the API. In NSX-T Data Center, if you have permission, you can clone an existing role, add a new role, edit newly created roles, or delete newly created roles.

Role-Based Access Control (vmware.com)
