PCNSA Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0) Question and Answers

When a security rule is configured as Intrazone, the destination zone field cannot be changed. This is because an intrazone rule applies to traffic that originates and terminates in the same zone. The destination zone is automatically set to the same value as the source zone and cannot be modified1. An intrazone rule allows you to control and inspect traffic within a zone, such as applying security profiles or logging options2. References: What are Universal, Intrazone and Interzone Rules?, Security Policy, Updated Certifications for PAN-OS 10.1, Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0) or [Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0)].

To block hosts that use bulletproof hosts to provide malicious, illegal, and/or unethical content, use the bulletproof IP address list in policy.

https://docs.paloaltonetworks.com/pan-os/9-0/pan-os-new-features/content-inspection-fea tures/edl-for-bulletproof-isps#:~:text=A%20new%20built%2Din%20external,%2C%20illegal%2C%20and%20unethical%20content.

Explanation

Explanation/Reference:

https://docs.paloaltonetworks.com/pan-os/9-0/pan-os-admin/app-id/manage-new-app-ids-introduced-in-content-releases/review-new-app-id-impact-on-existing-policy-rules

Security profiles are objects added to policy rules that are configured with an action of allow.

URL filtering technology protects users from web-based threats by providing granular control over user access and interaction with content on the Internet. You can develop a URL filtering policy that limits access to sites based on URL categories, users, and groups. For example, you can block access to sites known to host malware and prevent end users from entering corporate credentials to sites in certain categories.

In the FW you define an Auth sequence which specifies the Auth Profile. If you click add on an Auth Profile and define one named TACACS for example, the Auth Profile calls in the TACACS+ Server Profile.

An application filter is an object that dynamically groups applications based on application attributes that you define, including category, subcategory, technology, risk factor, and characteristic. This is useful when you want to safely enable access to applications that you do not explicitly sanction, but that you want users to be able to access. For example, you may want to enable employees to choose their own office programs (such as Evernote, Google Docs, or Microsoft Office 365) for business use. To safely enable these types of applications, you could create an application filter that matches on the Category business-systems and the Subcategory office-programs. As new applications office programs emerge and new App-IDs get created, these new applications will automatically match the filter you defined; you will not have to make any additional changes to your policy rulebase to safely enable any application that matches the attributes you defined for the filter.

https://docs.paloaltonetworks.com/pan-os/9-0/pa n-os-admin/app-id/use-application-objects-in -policy/create-an-application-filter.html

https://docs.paloaltonetworks.com/panorama/9-0/panorama-admin/manage-firewalls/manage -device-groups/create-objects-for-use-in-shared-or-device-group-policy

Explanation/Reference:

Static IP and Dynamic IP and Port (DIPP) are two features that implement one-to-one translation of a source IP address while allowing the source port to change. Static IP translates a single source address to a specific public address, and allows the source port to change dynamically1. Dynamic IP and Port (DIPP) translates the source IP address or range to a single IP address, and uses the source port to differentiate between multiple source IPs that share the same translated address2. Both of these features provide a one-to-one translation of IP addresses, but do not restrict the source port. References:

• Static IP - Palo Alto Networks
• Dynamic IP and Port - Palo Alto Networks

Domain generation algorithms (DGAs) are used to auto-generate domains, typically in large numbers within the context of establishing a malicious command-and-control (C2) communications channel. DGA-based malware (such as Pushdo, BankPatch, and CryptoLocker) limit the number of domains from being blocked by hiding the location of their active C2 servers within a large number of possible suspects, and can be algorithmically generated based on factors such as time of day, cryptographic keys, or other unique values.

https://docs.paloaltonetworks.com/pan-os/9-0/pan-os-admin/threat-pre vention/dns-security/domain-generation-algorithm-detection

• Enter the route and netmask
• Enter the IP address for the specific next hop
• Specify the outgoing interface for packets to use to go to the next hop
• Add an IPv4 or IPv6 route by name Comprehensive Explanation: This is the correct order of steps to create a static route in a virtual router on the firewall. The first step is to enter the route and netmask for the destination network, such as 192.168.2.2/24 for an IPv4 address or 2001:db8:123:1::1/64 for an IPv6 address. The second step is to enter the IP address for the specific next hop, such as 192.168.56.1 or 2001:db8:49e:1::1. The third step is to specify the outgoing interface for packets to use to go to the next hop, such as ethernet1/1. The fourth step is to add an IPv4 or IPv6 route by name, such as route11. References:

• Configure a Static Route - Palo Alto Networks

References:

To enable DNS sinkholing for domain queries using DNS security, you must activate your DNS Security subscription, create (or modify) an Anti-Spyware policy to reference the DNS Security service, configure the log severity and policy settings for each DNS signature category, and then attach the profile to a security policy rule.

https://docs.paloaltonetworks.com/pan-os/10-1/pan-os-admin/threat-prevention/dns-security/enable-dns-security

• An Anti-Spyware security profile is a set of rules that defines how the firewall detects and prevents spyware from compromising hosts on the network. Spyware is a type of malware that collects information from the infected system, such as keystrokes, browsing history, or personal data, and sends it to an external command-and-control (C2) server1.
• An Anti-Spyware security profile consists of four tabs: Signature Policies, Signature Exceptions, Machine Learning Policies, and Inline Cloud Analysis1.
• The Signature Policies tab allows you to configure the actions and log settings for each spyware signature category, such as adware, botnet, keylogger, phishing, or worm. You can also enable DNS Security to block malicious DNS queries and responses1.
• The Signature Exceptions tab allows you to create exceptions for specific spyware signatures that you want to override the default action or log settings. For example, you can allow a signature that is normally blocked by the profile, or block a signature that is normally alerted by the profile1.
• The Machine Learning Policies tab allows you to configure the actions and log settings for machine learning based signatures that detect unknown spyware variants. You can also enable WildFire Analysis to submit unknown files to the cloud for further analysis1.
• The Inline Cloud Analysis tab allows you to enable machine learning based engines that detect unknown spyware variants in real time. These engines use cloud-based models to analyze the behavior and characteristics of network traffic and identify malicious patterns. You can enable inline cloud analysis for HTTP/HTTPS traffic, SMTP/SMTPS traffic, or IMAP/IMAPS traffic1.

Therefore, the tab that is used to enable machine learning based engines is the Inline Cloud Analysis tab.

References:

1: Security Profile: Anti-Spyware - Palo Alto Networks

To reference the same address object in Security policies on 100 Panorama-managed firewalls, across 10 device groups and five templates, the administrator should ensure that the Shared option is checked when creating the address object. This option allows the administrator to create a shared address object that is available to all device groups and templates on Panorama. The shared address object can then be used in multiple firewall policy rules, filters, and other functions1. This reduces the complexity and duplication of managing address objects across multiple firewalls2. References: Address Objects, Create a Shared Address Object, Certifications - Palo Alto Networks, Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0) or [Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0)].

The Security profile that should be applied in order to protect against illegal code execution is the Vulnerability Protection profile on allowed traffic. The Vulnerability Protection profile defines the actions that the firewall takes to protect against exploits and vulnerabilities in applications and protocols. The firewall can block or alert on traffic that matches a specific threat signature or a group of threats. The Vulnerability Protection profile can prevent illegal code execution by detecting and blocking attempts to exploit buffer overflows, format string vulnerabilities, or other code injection techniques1. To apply the Vulnerability Protection profile on allowed traffic, you need to:

• Create or modify a Vulnerability Protection profile on the firewall or Panorama and configure the rules and exceptions for the threats that you want to protect against2.
• Attach the Vulnerability Protection profile to a Security policy rule that allows traffic that you want to scan for vulnerabilities3.
• Commit the changes to the firewall or Panorama and the managed firewalls.

References: Vulnerability Protection Profile, Create a Vulnerability Protection Profile, Attach a Vulnerability Protection Profile to a Security Policy Rule, Certifications - Palo Alto Networks, Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0) or [Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0)].

You can use an address object of type IP Wildcard Mask only in a Security policy rule.

https://docs.paloaltonetworks.com/pan-os/9-0/pan-os-web-interface-help/objects/objects-addresses

IP Wildcard Mask

—Enter an IP wildcard address in the format of an IPv4 address followed by a slash and a mask (which must begin with a zero); for example, 10.182.1.1/0.127.248.0. In the wildcard mask, a zero (0) bit indicates that the bit being compared must match the bit in the IP address that is covered by the 0. A one (1) bit in the mask is a wildcard bit, meaning the bit being compared need not match the bit in the IP address that is covered by the 1. Convert the IP address and the wildcard mask to binary. To illustrate the matching: on binary snippet 0011, a wildcard mask of 1010 results in four matches (0001, 0011, 1001, and 1011).

The best-practice approach to logging traffic that traverses the firewall is to enable log at session end only. This option allows the firewall to generate a log entry only when a session ends, which reduces the load on the firewall and the log storage. The log entry contains information such as the source and destination IP addresses, ports, zones, application, user, bytes, packets, and duration of the session. The log at session end option also provides more accurate information about the session, such as the final application and user, the total bytes and packets, and the session end reason1. To enable log at session end only, you need to:

• Create or modify a Security policy rule that matches the traffic that you want to log.
• Select the Actions tab in the policy rule and check the Log at Session End option.
• Commit the changes to the firewall or Panorama and the managed firewalls.

References: View and Manage Logs, Log at Session End, Certifications - Palo Alto Networks, [Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0)] or [Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0)].

Explanation/Reference:

By default, the firewall uses the management (MGT) interface to access external services, such as DNS servers, external authentication servers, Palo Alto Netw orks services such as soft ware, URL updates, licenses, and AutoFocus. An alternative to using the MGT interface is configuring a data port (a standard interface) to access these services. The path from the interface to th e service on a server is aservice route. [Palo Alto Networks]

PAN-OS 10 -> Device -> Setup -> Services -> Service Features -> Service Route Configuration

The application characteristics can be found in three places on the PAN-OS interface: Objects tab > Application Filters, Objects tab > Application Groups, and Objects tab > Applications. These places allow you to view and manage the applications and application groups that are used in your Security policy rules. You can also create custom applications and application filters based on various attributes, such as category, subcategory, technology, risk, and behavior1. Some of the characteristics of these places are:

Objects tab > Application Filters: An application filter is a dynamic object that groups applications based on specific criteria. You can use an application filter to match multiple applications in a Security policy rule without having to list them individually. For example, you can create an application filter that includes all applications that have a high risk level or use peer-to-peer technology.

Objects tab > Application Groups: An application group is a static object that groups applications based on your custom requirements. You can use an application group to match multiple applications in a Security policy rule without having to list them individually. For example, you can create an application group that includes all applications that are related to a specific business function or project.

Objects tab > Applications: An application is an object that identifies and classifies network traffic based on App-ID, which is a technology that uses multiple attributes to identify applications. You can use an application to match a specific application in a Security policy rule and control its access and behavior. For example, you can use an application to allow web browsing but block file sharing or social networking.

References: Objects, [Application Filters], [Application Groups], [Applications], Updated Certifications for PAN-OS 10.1, Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0) or [Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0)].

• A DNS policy action is a setting in an Anti-Spyware security profile that defines how the firewall handles DNS queries to malicious domains. A malicious domain is a domain name that is associated with a known threat, such as malware, phishing, or botnet1.
• There are four possible DNS policy actions: alert, allow, block, and sinkhole1.
• The alert action logs the DNS query and allows it to proceed to the intended destination. This action does not prevent hacking attacks, but only notifies the administrator of the potential threat1.
• The allow action allows the DNS query to proceed to the intended destination without logging it. This action does not prevent hacking attacks, but only bypasses the DNS security inspection2.
• The block action blocks the DNS query and sends a response to the client with an NXDOMAIN (non-existent domain) error code. This action prevents hacking attacks by preventing the client from resolving the malicious domain1.
• The sinkhole action redirects the DNS query to a predefined IP address (the sinkhole IP address) that is under the control of the administrator. This action prevents hacking attacks by isolating the client from the malicious domain and allowing the administrator to monitor and remediate the infected host1.
• The override action is not a valid DNS policy action, but a setting in an Anti-Spyware security profile that allows the administrator to create exceptions for specific spyware signatures that they want to override the default action or log settings3.

Therefore, the two DNS policy actions that can prevent hacking attacks through DNS queries to malicious domains are block and sinkhole.

References:

1: Enable DNS Security - Palo Alto Networks 2: How To Disable the DNS Security Feature from an Anti-Spyware Profile - Palo Alto Networks 3: Security Profile: Anti-Spyware - Palo Alto Networks

To enable the firewall to scan the traffic that it allows based on a Security policy rule, you must also attach Security Profiles —including URL Filtering, Antivirus, Anti-Spyware, File Blocking, and WildFire Analysis—to each rule. To attach a Security Profile to a Security policy rule, you must select Profiles as the Profile Type in the Actions tab of the rule. This allows you to choose from the predefined or custom Security Profiles that you have configured. Group-Profiles, Default-Profiles, and Tagged-Profiles are not valid options for attaching Security Profiles to Security policy rules. References: Set Up a Basic Security Policy, Security Profiles, Updated Certifications for PAN-OS 10.1

The NAT Target tab is a table that allows you to specify the target firewalls or device groups for each NAT policy rule on Panorama. This tab is available only on Panorama and not on individual firewalls. The NAT Target tab enables you to create a single NAT policy rulebase on Panorama and then selectively push the rules to the firewalls or device groups that require them. This reduces the complexity and duplication of managing NAT policies across multiple firewalls1. References: NAT Target Tab, NAT Policy Overview, NPTv6 Overview, Updated Certifications for PAN-OS 10.1.

GlobalProtect: GlobalProtect safeguards your mobile workforce by inspecting all traffic using your next-generation firewalls deployed as internet gateways, whether at the perimeter, in the Demilitarized Zone (DMZ), or in the cloud.

Reconnaissance – stage where the attacker scans for network vulnerabilities and services that can be exploited.

Installation – stage where the attacker will explore methods such as a root kit to establish persistence

Command and Control – stage where the attacker has access to a specific server so they can communicate and pass data to and from infected devices within a network.

Act on the Objective – stage where an attacker has motivation for attacking a network to deface web property

References:

The Policy Optimizer is a feature in the PAN-OS GUI that allows an administrator to monitor the rule usage for a specified period of time, as well as optimize the security policies based on the traffic logs and recommendations. The Policy Optimizer can help the administrator to improve the security posture, reduce the attack surface, and simplify the policy management. The Policy Optimizer can be accessed from Policies > Policy Optimizer in the PAN-OS GUI. References: Policy Optimizer, View Policy Rule Usage, Updated Certifications for PAN-OS 10.1

By default, the maximum number of templates that can be added to a template stack is 8. This is the recommended limit for performance reasons, as adding more templates may result in sluggish responses on the user interface. However, starting from PAN-OS 8.1.10 and 9.0.4, you can use a debug command to increase the maximum number of templates per stack to 16. This command requires a commit operation to take effect.

A template stack is a collection of templates that you can use to push common settings to multiple firewalls or Panorama managed collectors. A template contains the network and device settings that you want to share across devices, such as interfaces, zones, virtual routers, DNS, NTP, and login banners. You can create multiple templates for different device groups or locations and add them to a template stack in a hierarchical order. The settings in the lower templates override the settings in the higher templates if there are any conflicts. You can then assign a template stack to one or more devices and push the configuration changes.

References:

https://docs.paloaltonetworks.com/pan-os/9-0/pan-os-admin/app-id/manage-new-app-ids-introduced- incontent-releases/review-new-app-id-impact-on- existing-policy-rules

To see how new and modified App-IDs impact your Security policy, you need to follow the path Device > Dynamic Updates > Review App-IDs on PAN-OS 11.x. This option allows you to perform a content update policy review for both downloaded and installed content. You can view the list of new and modified App-IDs and their descriptions, and see which Security policy rules are affected by them. You can also modify the rules or create new ones to adjust your Security policy as needed1. References: See How New and Modified App-IDs Impact Your Security Policy, Updated Certifications for PAN-OS 10.1, Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0) or [Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0)].

• If you have Universal Groups, create an LDAP server profile to connect to the root domain of the Global Catalog server on port 3268 or 3269 for SSL, then create another LDAP server profile to connect to the root domain controllers on port 389. This helps ensure that users and group information is available for all domains and subdomains.

https://docs.paloaltonetworks.com/pan-os/9-1/pan-os-admin/user-id/map-users-to-groups

Threat Intelligence Cloud – Gathers, analyzes, correlates, and disseminates threats to and from the network and endpoints located within the network.

Next-Generation Firewall – Identifies and inspects all traffic to block known threats

Advanced Endpoint Protection - Inspects processes and files to prevent known and unknown exploits

Reverting to the running configuration will undo the changes made to the candidate configuration since the last commit. This operation will replace the settings in the current candidate configuration with the settings from the running configuration. The firewall provides the option to revert all the changes or only specific changes by administrator or location1. References: Revert Firewall Configuration Changes, How to Revert to a Previous Configuration, How to revert uncommitted changes on the firewall?.

URL Filtering profiles are configured in the Objects section of the PAN-OS GUI. A URL Filtering profile defines the actions that the firewall takes for different URL categories, such as allow, block, alert, continue, or override. You can also configure settings for credential phishing prevention, URL filtering inline machine learning, and safe search enforcement in a URL Filtering profile1. To create or modify a URL Filtering profile, you need to go to Objects > Security Profiles > URL Filtering2. References: URL Filtering Profile, Create a URL Filtering Profile, Updated Certifications for PAN-OS 10.1, Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0) or [Palo Alto Networks Certified Network Security Administrator (PAN-OS 10.0)].

References:
