M2 Commercial Mechanical Inspector Question and Answers

For commercial kitchen exhaust associated with Type I hood systems, the recognized code-based minimum duct transport velocity is 1,500 feet per minute , so C is the correct answer. Option B uses the wrong unit, and the other listed velocities do not match the code minimum used for this question type.

The ICC mechanical code provision for infrared radiant heaters states that the heaters must be installed with clearances from combustible material in accordance with the manufacturer’s installation instructions . That makes Option D the correct answer. The code does not establish a blanket 6-foot clearance on all sides in this section, and the exam expects the candidate to rely on the listed installation requirements for the appliance.

The ICC mechanical code requires the lowest portion of a floor furnace to have not less than 6 inches (152 mm) clearance from grade level . Therefore, the correct choice is the option corresponding to 6 inches , which is C based on your answer set.

This item appears to use older or simplified exam wording . Current ICC language for polyethylene plastic piping identifies heat-fusion joints, electrofusion joints, and stab-type insert fittings as the named PE joining methods, not solvent cement or threaded couplings. Among the answer choices you provided, D. Compression coupling is the only choice that aligns most closely with a mechanical fitting/joining approach for PE systems, while rubber cement, solvent cement, and threaded coupling do not match ICC PE joining practice. Because of that, D is the best answer from the listed options, but this question should be tied to the exact code cycle or source exam bank if you want absolute cycle-specific certainty

The IMC requires access openings for fire dampers to be of a size that allows maintenance and resetting of the damper . The code does not set the answer as same-as-duct, half-diagonal, or a universal 12-inch by 12-inch opening. So Option C is correct.

In the IMC hydronic piping provisions for ground-source heat pump loop systems, shutoff valves are required on both sides of a pressure-reducing valve . That matches D . Heat-fusion joints and change-in-material joints do not trigger this two-sided shutoff-valve requirement.

This is also an exhibit-reading question. From the equipment schedule in the image, CEF-5 is listed as a Nutone unit, so Option D is correct. This falls under reading commercial mechanical drawings and equipment schedules related to exhaust/ventilation components.

Based on the equipment schedule shown in the exhibit, EF-2 is listed with a motor size of 1.5 horsepower . Therefore, the correct answer is C .

Based on the specification sheet shown in the exhibit, the hood is fabricated of Type 430 stainless steel , and the optional stainless steel listed is Type 304 . Therefore, the correct answer is C .

The IFGC requires the appliance shutoff valve to be located in the same room as the appliance and within 6 feet of the appliance . Therefore, the correct answer is A .

The IMC combustion-air provisions require openings used for combustion air to have a minimum cross-sectional dimension of 3 inches . Where ducts are used, they must be of the same cross-sectional area as the openings to which they connect. That makes 3 inches the correct answer, so Option B is correct.

Solid-fuel cooking equipment requires a separate hood and exhaust system . It is not permitted to share the same hood/exhaust arrangement in the manner suggested by the other choices. This is a standard commercial kitchen exhaust requirement because of the added fire and residue hazards associated with solid-fuel appliances.
