JN0-452 Mist AI Wireless - Specialist (JNCIS-MistAI-Wireless) Question and Answers

In the architecture of Juniper Mist AI, the RESTful API is the foundational interface for all automation, monitoring, and configuration tasks.1 When building automation for a REST (Representational State Transfer) API, HTTPS (Hypertext Transfer Protocol Secure) is the protocol used as the transport mechanism. REST is an architectural style that leverages the existing standards of the web, and in the case of the Mist Cloud, it specifically mandates the use of HTTPS to ensure that all data transmitted between the automation script (the client) and the Mist Cloud (the server) is encrypted and secure.

HTTPS acts as the "delivery truck" for the API requests.2 It carries the HTTP methods—such as GET (to retrieve data), POST (to create new objects), PUT (to update existing ones), and DELETE (to remove them)—across the network to specific Mist API endpoints (e.g., api.mist.com). While the actual data being transported is typically formatted in JSON (JavaScript Object Notation), the underlying protocol that handles the connection, session negotiation, and data encapsulation is HTTPS.

Mist's "100% API" philosophy means that every feature available in the GUI is accessible via these HTTPS-based calls.3 This allows developers to use various tools and languages to interact with the platform. For example, a developer might write a script in Python (C) or use an orchestration tool like Ansible (A), but both of these will ultimately generate HTTPS requests to communicate with the Mist backend. Similarly, while some older APIs used XML (B) for data structure, modern RESTful services like Mist exclusively use JSON for its lightweight and human-readable properties.4 Therefore, HTTPS remains the essential transport layer that enables the secure, stateless communication required for scalable cloud-native automation.

The AI VALIDATED status update means that the issue was opened and Marvis confirms it has been closed.

According to the Marvis Virtual Network Assistant Datasheet1, the AI-VALIDATED status update means that the issue was opened and Marvis confirms it has been closed. This status indicates that Marvis has verified that the issue is no longer present and the root cause has been resolved.

the Post-Install user role is also known as Installer role, which has a minimum level of access to the org, sites, and APs. It can do the initial installation such as claim AP to Org, assign/unassign AP, or place on map, etc., but cannot unclaim or remove the AP from the Org. Site and AP access is allowed based on timed grace period and/or explicit site access.

https://www.mist.com/documentation/mist-ai-mobile-app/

To review and troubleshoot the roaming activity of a specific client within a Juniper Mist environment, administrators rely on the conversational and analytical power of the Marvis Virtual Network Assistant (D) and its underlying Marvis Query Language (C). While other Marvis components like Actions focus on organization-wide health and Minis focus on synthetic testing, the VNA and MQL are specifically designed for deep-dive investigations into individual client experiences.

The Marvis Virtual Network Assistant (VNA) serves as the primary interface for this task. It allows an administrator to interact with the Mist AI using natural language. By typing a request such as "Troubleshoot client [Client Name]" or "How was the roaming for [Client Name]?", Marvis VNA aggregates all relevant telemetry data—including signal strength (RSSI), AP transitions, and authentication timings—into a simplified, human-readable summary. It provides a visual timeline of where the client moved and whether each roam was successful, slow, or failed.

Behind the scenes, these natural language requests are often converted into or powered by the Marvis Query Language (MQL). MQL is a structured way to query the Mist Graph API. For specific roaming reviews, the ROAMINGOF clause is used to filter the massive Mist data set for events related only to that client's mobility. For example, a query like roaming of "User-1" during last 24 hours will return a detailed data set showing the "From AP" and "To AP" details, the delta in signal strength during the handoff, and any associated latency.

By using these two features together, administrators can distinguish between a "sticky client" (one that refuses to roam despite a better signal being available) and a "coverage hole" (where the signal drops too low before a new AP is detected). This AI-driven approach eliminates the need for manual packet captures or log parsing, significantly reducing the Mean Time to Repair (MTTR) for mobility-related issues.

According to the Cisco Catalyst 9800 Series Wireless Controller Software Configuration Guide2, a device profile is a configuration object that allows you to group similar devices together and apply consistent WxLAN policies across multiple sites. A device profile defines parameters such as device type, OS, and MAC address.

According to the Virtual Network Assistant | Juniper Networks US document, Asymmetry Downlink is a classifier under the Coverage SLE that tracks an AP that transmits at a lower data rate than a connected client. This can indicate poor coverage or interference issues that affect downlink performance.

In a traditional wireless environment, verifying the functionality of network services like DHCP, DNS, or captive portals requires a physical presence at the site or an active client to report telemetry. However, the Marvis Minis feature within the Juniper Mist AI ecosystem is specifically designed to solve the problem of "empty site" verification. Marvis Minis act as Digital Twins—virtualized client agents that reside directly on the Mist Access Points (APs).

Because they are integrated into the AP firmware, Marvis Minis can simulate client behavior without requiring any actual user devices to be connected to the WLAN. When an administrator wants to verify that DHCP is working on a specific SSID, Marvis Minis perform automated "synthetic testing." The virtual client will attempt to associate with the WLAN, complete the 802.11 authentication/association process, and then request an IP address via DHCP. If the DHCP server is unreachable, the pool is exhausted, or the response is too slow, Marvis Minis will detect this failure and report it to the Mist Cloud.

This proactive validation is part of Mist’s "Always-On" network testing strategy. While Marvis Actions (D) would eventually report a DHCP failure once real clients started failing, and Marvis Query Language (C) could be used to search for historical failures, only Marvis Minis (B) can actively test and verify the service in a scenario where there are currently no clients. This allows engineers to identify and fix "sleeping" issues—such as a misconfigured VLAN on a switch port or a downed DHCP server—before the first user even walks into the building, ensuring a "validated" network state at all times.

In Juniper Networks Mist AI Wireless, Juniper prescribes a top-down, structured troubleshooting methodology when using Service-Level Expectations (SLEs). This approach ensures that engineers identify systemic issues before drilling into individual client problems, preventing misdiagnosis and wasted effort.

The correct troubleshooting order is:

Organization → Site → SLE → Client

Organization of interestTroubleshooting always begins at the organization level. This provides a global view of overall health, license status, widespread outages, and configuration changes that may impact multiple sites. Organization-level visibility helps determine whether the issue is localized or systemic.

Site of interestAfter confirming the organization is healthy, the next step is narrowing the scope to the affected site. Site-level views expose infrastructure issues such as WAN problems, DHCP outages, AP connectivity issues, or RF-wide anomalies that affect many users simultaneously.

SLE of interestOnce scoped to the site, administrators identify the specific degraded SLE (for example, Time to Connect, Coverage, Capacity, or Throughput). Each SLE includes classifiers that pinpoint the likely root cause, such as DHCP, DNS, authentication, or RF interference.

Client of interestOnly after isolating the failing SLE should troubleshooting move to the individual client level. Client views provide detailed timelines, event history, and packet-level insights to confirm whether the issue is isolated or a symptom of a broader problem.

The other answer choices are incorrect because they start with either the SLE or client, which risks overlooking organization-wide or site-wide conditions. Juniper’s recommended workflow ensures efficient, accurate fault isolation and aligns with how Mist AI correlates telemetry and events.

Therefore, the correct answer is A. Organization of interest, site of interest, SLE of interest, client of interest.

According to Coverage SLE, Asymmetry Downlink classifier tracks a client that transmits at lower data rate than AP to which it is connected.So the correct answer is A.Asymmetry Downlink

Two correct statements about Juniper Mist Dynamic Packet Capture are that no configuration is necessary for Mist’s Dynamic Packet Capture and it is automatically attached to a client event displayed on the Insights page. So the correct answers are A. No configuration is necessary for Mist’s Dynamic Packet Capture and B. It is automatically attached to a client event displayed on the Insights page.

According to the JNCIS-MistAI Certification page3, a Marvis Actions Missing VLAN notification indicates that an access point is missing a VLAN that is configured on other access points in the same site.

According to the Webhooks - Mist document, two types of information that would be streamed through webhooks are:

Alerts, which are notifications that are triggered by certain events or conditions on the network.

SLE metrics of clients, which are service level expectations that measure the quality of experience for clients on various aspects such as connection, coverage, capacity, throughput, and roaming.

According to the exhibit, the WLAN has a minimum basic rate of 24 Mbps for both 2.4 GHz and 5 GHz bands. This corresponds to the high-density data rate setting in Mist, which disables all data rates below 24 Mbps. This setting is recommended for high density designs, where clients have enough signal strength and quality to operate at higher rates.

According to the Lecture 3 - Radio Frequency and Antenna Fundamentals - Part 2 document2, an extended service set (ESS) is a group of basic service sets (BSSs) that share a common SSID and are connected by a distribution system (DS). Each BSS within the ESS has its own unique BSSID, which is the MAC address of the AP.

In Juniper Networks Mist AI Wireless, understanding modulation schemes is essential for designing and operating high-performance Wi-Fi 6 (802.11ax) networks. Modulation directly affects how much data can be transmitted per symbol, and therefore determines the maximum achievable data rates under optimal RF conditions.

802.11ax introduces 1024-QAM (Quadrature Amplitude Modulation) as its highest supported modulation scheme. With 1024-QAM, each symbol encodes 10 bits of data, which represents a significant increase compared to earlier standards. For reference:

64-QAM (used in earlier standards) carries 6 bits per symbol

256-QAM (introduced in 802.11ac) carries 8 bits per symbol

1024-QAM increases this to 10 bits per symbol

This higher bit density allows Wi-Fi 6 devices to achieve higher peak throughput, especially in environments with excellent signal quality. However, 1024-QAM requires very high Signal-to-Noise Ratio (SNR) and low interference to function reliably. As a result, it is typically achieved only when clients are close to the access point and RF conditions are clean.

Mist AI Wireless continuously monitors client RSSI, SNR, retransmissions, and modulation rates through advanced telemetry. Using this data, Mist can determine whether clients are successfully operating at higher modulation levels like 1024-QAM or are falling back to lower schemes due to RF impairments. This insight directly feeds into SLEs and AI-driven recommendations for RF tuning, AP placement, and channel planning.

The incorrect options are explained as follows:

64-QAM and 256-QAM are valid modulation schemes but do not provide the highest data rates in 802.11ax.

4096-QAM is not supported by the 802.11ax standard and is therefore invalid.

Thus, 1024-QAM is the modulation scheme that provides the highest data rate level for 802.11ax devices.

According to the Lecture 3 - Radio Frequency and Antenna Fundamentals - Part 2 document3, two layers that are different between Ethernet and Wi-Fi in the OSI networking model are:

Media access control (MAC) sub-layer, which is part of the data link layer and defines how devices access and share the wireless medium.

Physical layer, which defines how data is encoded and transmitted over the wireless medium.

According to the Wi-Fi configuration with Mist Systems | HCD Consulting GmbH document, three available rate limiting options in the Mist UI are:

 The AP Offline Marvis Action will consider all APs assigned to sites that have connected to the cloud previously for inclusion. So the correct answer is A. all APs assigned to sites that have connected to the cloud previously.

The 37% of Successful Connects suggest that 63% failed – however, these are spread between both LD_Testbed_MD and LD_RS_Support. If the only AP with connection issues was LD_RS_Support then the reverse math may have worked.

According to the Virtual Network Assistant | Juniper Networks US document2, Time to Connect is a Wireless Assurance SLE that has classifiers of Association, Authorization, DHCP, and Internet Services. This SLE measures how long it takes for a client device to connect to the network and access internet services.

 According to the Cisco Catalyst 9800 Series Wireless Controller Software Configuration Guide1, RF templates are assigned to sites, which are logical groupings of devices based on physical location or other criteria. RF templates allow you to configure RF parameters such as channel width, transmit power, and data rates for multiple devices at once.

According to the Mist documentation1, a Mist AP will pull a management IP address from the Native VLAN by default. However, if the Local Status Page is configured for the Site, all the site APs will pull their own IP address from the Management VLAN, but also addresses for each of the VLANs configured on the AP. This is because each AP creates a Switch Virtual Interface (SVI) for each VLAN on its eth0 interface.

The Local Status Page is a feature that allows you to access information about an AP’s status and configuration through a web browser by connecting to its IP address2. This feature can be enabled or disabled at the site level under Site Settings > Access Points > Advanced Settings.

Juniper Mist separates its Location-Based Services (LBS) into distinct functional areas: User Engagement (vBLE-based) and Asset Visibility (tracking assets via Wi-Fi or BLE). Understanding the licensing and default behavior is crucial for a successful deployment.

The Wi-Fi location component is designed to track devices that are connected to the Wi-Fi network or are simply probing (unconnected). While basic connectivity data is part of the standard management, the high-fidelity tracking of these devices on a map as "assets" or "clients" for location analytics is tied to specific licensing tiers.

First, Wireless Assurance (B) provides the foundational telemetry and data collection required for basic location visibility. However, to unlock the full "Asset Tracking" capabilities—where the system actively correlates coordinates and provides historical data for specific Wi-Fi devices—the Asset Visibility subscription (D) is required. This subscription is what enables the Mist Cloud to process and store the location data for tags and Wi-Fi clients beyond simple real-time display.

Regarding the other options: Statement A is incorrect because the Wi-Fi location component tracks Wi-Fi devices; tracking BLE tags (third-party or otherwise) falls under the BLE/vBLE location component. Statement C is incorrect because location services are typically not enabled by default to protect user privacy and optimize performance. An administrator must manually upload a floor plan, scale it, and enable "Wi-Fi Engagement" or "Asset Tracking" within the Site settings or individual Access Point configurations to begin collecting location data. Once enabled and properly licensed, the Mist AI engine uses RSSI data from multiple APs to provide location coordinates for any Wi-Fi-emitting device in the environment.

In the Juniper Mist dashboard, managing licenses is handled through the Subscriptions page at the Organization level. This page is critical for ensuring that all deployed hardware (Access Points, Switches, and Gateways) has the necessary cloud services—such as Wi-Fi Assurance, Wired Assurance, or Marvis VNA—to function correctly. The subscription page provides a real-time overview of the organization's licensing health using specific status indicators.

The status Active (D) indicates that the subscription is currently within its valid date range and is being utilized by the hardware in the organization. When a subscription is marked as Active, it means the features associated with that license are fully operational, and the Mist Cloud is actively processing telemetry from the associated devices. This is the primary state for all correctly provisioned licenses.

The status Exceed (B) (often displayed as "Exceeded") is a unique and important state in the Mist ecosystem. Unlike many legacy controllers that might shut down services if a license count is surpassed, Mist uses an "honor-based" system combined with clear visual alerting. The Exceed status appears when the number of physical devices claimed and assigned to a site exceeds the total number of available license seats for a specific service. For example, if an organization has 100 "Wi-Fi Assurance" subscription seats but has deployed 110 Access Points, the status will show as Exceeded.

Mist provides a grace period and persistent notifications to administrators to rectify this by either purchasing more subscriptions or removing excess devices. It is important to note that while terms like "Valid" or "Demo" might be used in general conversation, the specific operational statuses tracked in the subscription table to manage license compliance and expiration are Active, Exceeded, and Expired. These statuses allow IT teams to proactively manage their operational expenditures and ensure uninterrupted service for their wireless users.

When using location-based services (LBS) at a new warehouse and placing APs on the floor plan with correct scale while ensuring correct location accuracy in this scenario where APs are mounted on trusses 14 feet (4.3 meters) from floor, two actions that should be taken are installing Virtual Beacons in each aisle and configuring height of each AP. So the correct answers are A. Install Virtual Beacons in each aisle and B. Configure height of each AP.

Transmissions over Wi-Fi are shared medium and half-duplex.

According to the IEEE 802.11 - Wikipedia document2, two terms that correctly describe transmissions over Wi-Fi are:

Shared medium, which means that multiple devices use the same wireless channel and have to compete for access and avoid collisions.

Half-duplex, which means that devices can either transmit or receive data at a time, but not both simultaneously.

Two authentication methods that would be used with a guest portal are social login and external portal. So the correct answers are A. social login and B. external portal.

According to the Cisco Catalyst 9800 Series Wireless Controller Software Configuration Guide2, two authentication methods that can be used with a guest portal are:

Social login, which allows guests to log in using their social media accounts such as Facebook, Twitter, or Google.

External portal, which allows guests to log in using an external web server that hosts a custom portal page.

Channel bonding combines two adjacent channels to create a wider channel, effectively doubling the available bandwidth. However, this also doubles the required device resources such as power and processing.

According to the Lecture 3 - Radio Frequency and Antenna Fundamentals - Part 2 document2, channel bonding is a technique that combines two adjacent channels into one wider channel to increase throughput. This doubles the available bandwidth but also doubles the required device resources such as power and processing.

According to the Virtual Network Assistant | Juniper Networks US document3, two SLEs that measure the amount of time that it takes for a process to complete are:

Roaming, which measures how long it takes for a client to switch from one AP to another without losing connectivity.

Time to Connect, which measures how long it takes for a client to complete all steps of network access such as authentication, DHCP, and DNS.
